Introduction
This machine is a rope continuous washing machine:
1. Reasonable structure design high degree of automation simple operation and less labor;
2. The cabinets are arranged compactly and occupy a small area;
3. The maximum cloth capacity of each tank is 100 meters and the soaping time is sufficient;
4. The cloth of two adjacent grooves of each unit is flushed back and forth through the cloth lifting wheel and nozzle with strong washing power;
5. The overall water flow is grid by grid with high water utilization rate and low water consumption. Wide range of technology high production speed strong applicability and other characteristics.

Machine speed:50m/min
Working width:1800-3600mm
Heating method:Steam
Steam and compressed air pressure:0.4MPa
Total power:45KW
Overall dimension(Type220):(L×W×H)17700×4100×2800mm

Machine speed:60m/min
Working width:1800-3600mm
Heating method:Steam
Steam and compressed air pressure:0.4MPa
Total power:105KW
Overall dimension(Type220):(L×W×H)31000×4100×2900mm

Machine speed:60m/min
Working width:1800-3600mm
Heating method:Steam
Steam and compressed air pressure:0.4MPa
Total power:55KW
Overall dimension(Type220):(L×W×H)24400×4100×2900mm

Machine speed:60m/min
Working width:1800-3600mm
Compressed air pressure:0.4MPa Total power: 17KW
Rolling mill type:Horizontal uniform rolling mill
Feeding system:Automatic feeding of mixing proportion pump produced in Germany
Overall dimension(Type220):(L×W×H)5000×3630×2600mm
